Body Structure and Material of Mobile Food Trailer
When buying a mobile food trailer, you need to pay attention to many quality-related factors. Quality is not only related to the life of the food trailer but also to your business. The body structure and material of the mobile food trailer are two very important factors that affect the quality. Read to learn more about body structure and materials.
Body structure
The body structure is divided into inner wall and outer wall. Below we introduce the materials of different structural layers of the body according to different models.
220 series food trailer
Inside Wall: 3.5mm thickness aluminum plastic board (the back working
bench is with a height of 30cm, 1.0mm thickness stainless steel
Panel), 25mm thickness black insulation cotton.
External Wall: 1.2mm thick cold rolled steel plate.
Working Table: 1.0mm thickness stainless steel & 8mm thickness wooden board.
Corridor: 1.0mm thickness galvanized sheet,8mm wooden board & 1.5mm non-slip aluminum sheet.
R series food trailer
Inside Wall: 3.5mm thickness aluminum plastic board (the back working
bench is with a height of 30cm,1.0mm thickness stainless steel
Panel),25mm thickness black insulation cotton.
External Wall: 1.2mm thick cold rolled steel plate and corner is with 0.8mm thickness stainless steel ball.
Working Table: 1.0mm thickness stainless steel & 8mm thickness wooden board.
Corridor: 1.0mm thickness galvanized sheet,8mm wooden board & 1.5mm non-slip aluminum sheet.
Airstream Food Trailer
Inside Wall: 3.5mm thickness aluminum plastic board (the back working
bench is with a height of 30cm,1.0mm thickness stainless steel
Panel),30mm thickness black insulation cotton.
External Wall: 0.8mm bright stainless steel.
Working Table: 1.0mm thickness stainless steel & 8mm thickness wooden board.
Corridor: 1.0mm thickness galvanized sheet,8mm wooden board & 1.5mm non-slip aluminum sheet.
Boat type food trailer
Inside Wall: 3.5mm thickness aluminum plastic board (the back working
bench is with a height of 30cm,1.0mm thickness stainless steel
Panel),25mm thickness black insulation cotton, 7mm thickness wooden sheet.
External Wall: 40mm thickness XPS( Outside is Steel,Inner is Cotton Insulation,Inside is Steel) (Advantages of XPS: Good insulation,Compression resistance,Moistureproof, Light Weight,Good Corrosion,Eco-environmental),
or 1.2mm cold rolled steel plate.
Working Table: 1.0mm thickness stainless steel & 8mm thickness wooden board.
Corridor: 1.0mm thickness galvanized sheet,8mm wooden board & 1.5mm non-slip aluminum sheet.
Extruded board square food trailer
Inside Wall: 3.5mm thickness aluminum plastic board (the back working
bench is with a height of 30cm, 1.0mm thickness stainless steel
Panel).
External Wall: 40mm thickness XPS( Outside is Steel, Inner is Cotton Insulation, Inside is Steel) (Advantages of XPS: Good insulation,Compression resistance, Moisture proof, Light Weight, Good Corrosion, Eco-environmental),
and 1.2mm cold rolled steel plate.
Working Table: 1.0mm thickness stainless steel & 8mm thickness wooden board.
6).Corridor: 1.0mm thickness galvanized sheet,8mm wooden board & 1.5mm non-slip aluminum sheet.
Cold plate square food trailer
Inside Wall: 3.5mm thickness aluminum plastic board (the back working
bench is with a height of 30cm, 1.0mm thickness stainless steel
Panel), 25mm thickness black insulation cotton, 8mm thickness wooden sheet.
External Wall: 1.2mm cold rolled steel plate.
Working Table: 1.0mm thickness stainless steel & 8mm thickness wooden board.
Corridor: 1.0mm thickness galvanized sheet,8mm wooden board & 1.5mm non-slip aluminum sheet.
Different types of mobile food trailers use different structural materials. In the next article, we will continue to learn the materials of the body structure used by other types of food trailers.
